Gigabyte
Radeon RX 7800 XT GAMING OC 16G
The current king of 1440p value, this card offers 16GB of VRAM and excellent rasterization performance for its price point.
$639.00
Key Properties
Boost Clock2565
Capacity(GB/W)16 GB/W
Card Length302
CompatibilityPCI Express 4.0 x16
Component TypeGPU
Cooling DesignOpen-air triple-fan
Dimensions(mm)302 x 130 x 56 mm (L x W x H), Slot width: 2.7 slots
Display Outputs['2x DisplayPort 2.1', '2x HDMI 2.1']
Encoder Decoder Features['AV1 encode/decode', 'H.264/H.265 encode/decode']
Form FactorATX
Form Factor Slot Width2.5
Gpu ArchitectureAMD RDNA 3
Gpu ModelAMD Radeon RX 7800 XT
Interface StandardPCIe 4.0 x16
ManufacturerGigabyte
Max Supported Displays4
Memory Bandwidth624
Memory Bus Width256
Pcie InterfacePCIe 4.0 x16
Performance SpecBoost Clock up to 2565 MHz, Game Clock up to 2254 MHz
Power Connectors['2x 8-pin']
Power Draw Tgp263
Power Requirements(W)263 W
Price(USD)639 USD
Ray Tracing SupportYes
Recommended Psu Wattage700
Thermal DesignWINDFORCE cooling system with three 90mm fans (7 composite copper heat pipes, large copper plate, 3D active fan semi-passive cooling)
Upscaling Technology['AMD FSR']
Vram Capacity16
Vram TypeGDDR6
Warranty Length3
